optical coherence tomography equipment computer controlled
ophthalmic imaging system
Optical Coherence Tomography Machine images showed that fluid from
the retinal detachment or cleavage cavity had channels leading
behind the optic nerve and had no communication with the vitreous
body. Optical Coherence Tomography Machine helps us to reunderstand
the nature of the disease, but OCT clearly shows that the macular
neurocortex has thinned and almost disappeared. If pathological
myopia does not have crack again of extremely shallow break off or
be amalamative retinal split, retinal split can be seen at
congenital and a variety of diseases such as inflammation, trauma,
denaturation, be in pathological myopia nevertheless more see.
For-patients who have an allergic reaction to strong light or
cannot accept light stimulation. Consult a doctor before imaging.
Compact Design
Features:
1. Compact Design: Everything is inside this compact body. No
external computer is needed. Plug in the power cable, then you are
ready to go.
2. PC Inside: Data acquisition and processing are accomplished by
the internal computer. The data can be transported via ethernet or
external harddrive. Peripheral devices, such as keyboard or
printer, can be connected to the computer ports.
3. Easy Installation:No complex connection or setup. Compact body
can fit in even small space.
Specifications of Optical Coherence Tomography Machine
| Methodology | Spectral domain OCT |
| Axial resolution | ≤6 µm (in tissue) |
| Transverse resolution | ≤20 µm (in tissue) |
| Scan depth | ≥2.5 mm (in air) |
| Scan range | ≥6 mm |
| Scan speed | ≥24,000 A-scans/sec, up to 36,000 A-scans/sec |
| Scan modes | 3D, Raster, Circle |
| Fundus image | OCT en face |
| Focus adjustment | -15D to +15D |
| Pupil diameter | ≥3mm |
| OCT light source | 840 nm SLD |
| Optical power | 750 µW (at cornea) |
| Operation | 13.3” touch screen, optional external mouse or keyboard |
| Power supply | 100-240 V, 50/60 Hz |
| Dimensions Weight | 34 kg (75 lbs) |
Company Introduction
Focusing on the two major public health problems of adolescent
myopia and elderly ophthalmology, our company researches new
diagnostic and treatment equipment for ophthalmology, develops
low-cost applicable technology products, realizes
industrialization, reduces the cost of social medical and health
system, and serves the strategic needs of national health.The company always adhere to the "high-tech,new vision" for the enterprise development
concept.We have a strong technical force, has been awarded 11 patents, and
obtained 13,485 quality system certification.Bio has established an efficient marketing team and a perfect
after-sales service system to provide medical equipment with the
highest cost performance and meticulous service.
